Hello friends,
Years back I got sick 'n tired of mounting cab lights with a tape measure, painters tape and a prayer they'd line up right. So I took the liberty of designing these templates. They took a great deal of time to make and are made to the exact specifications of OEM.
This listing is for an installation template for your 5th Gen (2019-2022) Dodge Ram.
Used for OEM lights with the square clip in design with one screw. Requires a dremel. Measure, measure ,measure and do not attmeltif you have any doubts. These work with the Mopar OEM and Recon LED OEM.
I also offer one for Recon aftermarket lights as well if you don't want to cut out the square clip in OEM design. That design requires the drilling of 3 holes for mounting.
Always use silicone to ensure no leaks.
Installation tips:
Factory measurements are 3.5" from windshield and 3.5" laterally. Where template template is marked "split" cut accordingly while assuring center 3 lights are centered and secure. Following that outer left and right lights are meant to be set 3.5" from the windshield and 3.5" from the outermost left or right.
These are made for precision accuracy when mounting cab lights to your Dodge Ram 1500/2500/3500, Cummins or gasser.
I also have templates for 1st gen Dodge Rams and Ram Chargers, for all generations of Chevy Silverado 2500 3500 Duramax, and all generations of Ford F250 F350 OBS and Powerstroke.
*Patent Pending: Upon you purchasing this template directly or via 3rd party, or coming in possession of this template, you are entering in an agreement with the seller, DieselHead, LLC, that you are possessingit with the intent to use it as it's intended purpose. Upon acquisition of this and any templates designed and sold by DieselHead, LLC you are agreeing that you will not be copying it or duplicating it in any capacity or acquiringit to modify the design and reproduce it to sell, distribute or resell in any and all capacities.*
My design is registered and Copyrighted. I am the original cab light template guy formerly known as "liftedchevy11" on here before I changed my name.
Please don't support or buy a thefted copy, buy the original and support an honest person. For the few people who have tried to steal my work and to those who might, I will take legal action.
Keep turning your own wrench and enjoy the satisfaction of doing the job yourself !!
***** I have to state a disclaimer that upon purchasing this you as the buyer are responsible for the installation. Do not even attempt if you doubt your mechanical abilities. Make sure before you drill you have the correct lights and while this template gives you the platform to install them, you are responsible for confirming that they are aligned to your liking. My templates give you some room to adjust forward and back and side to side. There are no install instructions included. I cannot be responsible for a botched install and that's why I cannot stress enough if you doubt your abilities or not mechanical inclined - pay a shop to do it.******
Thanks so much everyone and God bless you and your families.
