Specification:
Condition:100% Brand New And High Quality
Operating Frequency:433MHz
Manufacturer Part Number:13598773
Reference Number:13598773, 13516165, 13512347, 13522631, 13540603
Features:1.Guaranteed to fit and meet the specifications of the parts being replaced
2.Utilizes the latest in design and material technology, ensuring quiet and maintenance-free experience
3.Advanced manufacturing technology ensures durability and optimum operation
4.Providing the same performance, durability, and service life.
5.High-precision air valve to prevent air leakage
6.Safe and Reliable --- It is suitable for monitoring the internal pressure,temperature and other information of the tire,avoiding traffic accidents caused by tire failure,provide you with a better safety in the driving process.
Package Content:
4Pcs Tire Pressure Sensor
Comprehensive Vehicle Coverage:
For Buick Encore GX 2020
For Buick LaCrosse(433MHz) 2017-2019
For Buick Regal & TourX(433MHz) 2018-2020
For Cadillac CT4(433MHz) 2020
For Cadillac CT6(433MHz) 2016-2020
For Cadillac Escalade(433MHz) 2018
For Cadillac XT4(433MHz) 2018-2020
For Cadillac XT5(433MHz) 2016-2020
For Cadillac XT6(433MHz) 2020
For Chevrolet Blazer(433MHz) 2019-2020
For Chevrolet Bolt EV(433MHz) 2017-2018
For Chevrolet Cruze(NON LIMITED) 2016
For Chevrolet Cruze(433MHz) 2017-2019
For Chevrolet Malibu(433MHz) 2016-2020
For Chevrolet Silverado 1500(433MHz) 2017-2020
For Chevrolet Silverado 2500(433MHz) 2017-2020
For Chevrolet Silverado 3500(433MHz) 2017-2020
For Chevrolet Suburban(433MHz) 2018
For Chevrolet Tahoe(433MHz) 2018
For Chevrolet Volt(433MHz) 2018
For GMC Acadia(433MHz) 2017-2020
For GMC Sierra 1500(433MHz) 2017-2020
For GMC Sierra 2500(433MHz) 2017-2020
For GMC Sierra 3500(433MHz) 2017-2020
Optimized Installation Process:
Deflate the Tire:
Remove the valve cap and core to fully deflate the tire.
Dismount the Tire:
Secure the tire onto the tire changer and position the valve at the 1 o’clock position relative to the tire separation head. Use a tire tool to lift the bead over the mounting head and dismount the tire.
Remove the Sensor:
Using a screwdriver, remove the fastening screw and sensor from the valve stem. Then loosen the nut and completely remove the valve.
Install the Sensor and Valve:
Insert the valve stem through the valve hole on the rim. Secure the screw-nut with a torque of 4.0 Nm using a positioning pin for alignment. Attach the sensor body against the rim and tighten the mounting screw.
Mount the Tire:
Position the tire onto the rim, ensuring the valve is oriented 180 degrees opposite the separation head. Carefully seat the tire bead over the rim edge.
