BMW G30 G31 G38 · F90 M5 RGB DRL Module — App & Remote Controlled · Full Color Spectrum · Fading · Flashing · Strobe · E-Mark · RoHS Certified · 1-Year Warranty
Full RGB color control for your factory Icon Adaptive LED headlights without replacing the housings. This module replaces the LED board inside your existing DRL assembly and puts every color in the visible spectrum under your control.
Full RGB spectrum — white, yellow, amber, red, blue, green, purple, teal, and every gradient between them.
Two ways to control it — the Happy Lighting app over Bluetooth, or the included remote. Use whichever is easier in the moment.
Fading, flashing, and strobe modes — a full suite of dynamic lighting patterns, all adjustable.
Set it and forget it — the color holds until you change it. Nothing depends on your phone while driving.
FITMENT — ICON ADAPTIVE LED PRE-LCI ONLY
This module fits factory Icon Adaptive LED headlights (Option S552A) on pre-LCI builds only. It does not fit standard LED headlights or LCI builds.
Standard LED headlights use entirely different assemblies and are not compatible. Not sure which you have? Message us with your VIN before ordering and we’ll confirm your configuration. No guesswork. No returns.
YearMakeModelBody StyleChassis2017–2020BMW530i / 530i xDriveSedanG302018–2020BMW530e / 530e xDriveSedanG302017–2020BMW540i / 540i xDriveSedanG302018–2020BMWM550i xDriveSedanG302017–2020BMW5 Series TouringWagonG312017–2020BMW5 Series Long WheelbaseSedanG382018–2020BMWM5 / M5 CompetitionSedanF90
Does NOT fit: standard LED equipped builds (S5A1A) · LCI builds 2021+ · F10 F11 previous generation 5 Series · G32 6 Series Gran Turismo
OEM PART NUMBERS
DRL / Angel Eye Light Modules
▸ Left — 63117214939
▸ Right — 63117214940
Turn Signal Modules
▸ Left — 63117214941
▸ Right — 63117214942
Main LED Control / Ballast Module
▸ 63117463515 · Interchange 63117476487
Fits Icon Adaptive LED assemblies (S552A)
▸ Left — 63117214965 · 63117214961 · 63117439197 · 7214965 · 7439197
▸ Right — 63117214966 · 63117214962 · 63117439198 · 7214966 · 7439198
Standard LED assemblies (63117214959 / 63117214960) are not compatible. Check the sticker on your headlight housing or send us your VIN and we’ll verify before you order.
INSTALLATION — PROFESSIONAL INSTALLATION RECOMMENDED
This is a retrofit module that installs inside your existing headlight assembly. It requires removing the factory DRL module and replacing the internal LED board. Professional installation by a qualified automotive electrician is strongly recommended.
01 — In your iDrive settings, turn off the daytime running light option. Open the hood.
02 — Remove the factory daytime running light module from the headlight assembly.
03 — Remove the original LED light board from the module.
04 — Apply the included dielectric grease to the back of the RGB light board and mount it to the heat sink.
05 — Lift the waterproof gasket on the factory module, route the RGB ribbon cable underneath it, and reseat the module. Do not overtighten the screws — excess pressure on the ribbon cable causes color desynchronization or complete failure of the module.
06 — Connect the RGB connectors on both sides.
07 — Download the Happy Lighting app or use the included remote, and confirm color control is working on both sides before closing everything up.
WHAT’S IN THE BOX
▸ Left and right RGB DRL modules
▸ Remote control
▸ Dielectric grease
▸ Connection hardware
FEATURES
▸ Full RGB spectrum — every color, controlled by app or remote
▸ Happy Lighting app control — free on iOS and Android, Bluetooth connected
▸ Remote included — control color without reaching for your phone
▸ Fading · Flashing · Strobe modes — full suite of dynamic patterns
▸ Icon Adaptive LED fitment — G30, G31, G38 and F90 M5, 2017–2020, Option S552A only
▸ E-Mark · RoHS Certified
▸ 1-Year manufacturer warranty — backed by GlobalPace
▸ Dielectric grease included
▸ Ships from our US warehouse — 2–5 day delivery
SHIPPING & WARRANTY
Ships within 1–3 business days while stock lasts. Backed by GlobalPace’s 1-year manufacturer warranty. Message us through before initiating any return. Warranty claims are reviewed by our manufacturer and typically take 5–10 business days to process once documentation is submitted.
Message us with your VIN before ordering and we’ll confirm whether your build has Icon Adaptive LED headlights. No guesswork. No returns.
