For Small Block Chevy SBC 305 327 350 5.7\" H-Beam Connecting Rods 4340 Steel For Sale - New and Used

For Small Block Chevy SBC 305 327 350 5.7\" H-Beam Connecting Rods 4340 Steel

Performance Connecting Rods, 7/16 Bolts

Connecting Rod Length : 5.700\"

Rod Journal Diameter: 2.100\"

Wrist Pin Diameter:0.927\"

Connecting Rod Bolt :7/16\"

Connecting Rod Type: H-Beam

Big End Bore Diameter: 2.2250\"

Big End Width: 0.945\"

Connecting Rod Bolt Material: Chromoly steel

Fastener Yield Strength (psi): 200,000 psi

Connecting Rod Bolt Head Style: 12-point

Advertised Horsepower Rating (hp): 750 hp

Advertised RPM Rating: 7,500 rpm

Wrist Pin Style: Floating

Rod Material: Forged 4340 Steel

Package:

One set of 8 Connecting Rods（with bolts）

Professional Installation is Highly Recommended (No Instruction and Wiring Diagram Included)

---
