Fit Chevrolet models:
∙For 1996-2005 Chevrolet Astro -V6 4.3L
∙For 1996-2005 Chevrolet Blazer -V6 4.3L
∙For 1996-1998 Chevrolet C1500 -V6 4.3L
∙For 1996-2014 Chevrolet Express 1500 -V6 4.3L
∙For 1996-2005 Chevrolet Express 2500 -V6 4.3L
∙For 1996-1998 Chevrolet K1500 -V6 4.3L
∙For 1996-1999 Chevrolet P30 -V6 4.3L
∙For 1996-2004 Chevrolet S10 -V6 4.3L
∙For 1999-2013 Chevrolet Silverado 1500 -V6 4.3L Fit GMC models:
∙For 1996-1998 GMC C1500 -V6 4.3L
∙For 1996-2002 GMC Jimmy -V6 4.3L
∙For 1996-1998 GMC K1500 -V6 4.3L
∙For 1996-1999 GMC P3500 -V6 4.3L
∙For 1996-2005 GMC Safari -V6 4.3L
∙For 1996-2013 GMC Savana 1500 -V6 4.3L
∙For 1996-2006 GMC Savana 2500 -V6 4.3L
∙For 1999-2013 GMC Sierra 1500 -V6 4.3L
∙For 1996-2004 GMC Sonoma -V6 4.3L Fit Isuzu models:
∙For 1997-2000 Isuzu Hombre -V6 4.3L Fit Oldsmobile models:
∙For 1996-2001 Oldsmobile Bravada -V6 4.3L Part Number:
·Fuel Injector: 19210688, 12568332, 88894353.
·Fuel Injector Motor: 17113273.
· Replace Manufacture Part Numbers: FJ503, FJ10565, 217-3028, 2173028, 89060439, 833-22102-6, 25331863, 800-1512N, 17113295, 17114164, 17091628. Specification:
· 100% quality assurance tested, more responsive, less expensive, easier to install.
· Precisely trimmed solenoid windings enable optimum fuel delivery.
· High-temp O-rings enable prolonged sealing of injector under extreme heat conditions.
· Help you attain maximum fuel efficiency and power from your engine.
· Keep your vehicle performing reliably, efficiently, and safely for many miles to come.
· Promote smooth engine operation and balanced fuel delivery reducing overall fuel consumption and harmful emissions.
· Stainless steel calibration slide and spring assembly prevents corrosion within the fuel control body leading to an extended service life. Package insides:
1 x Fuel Injector
1 x Bracket
1 x Screw
(Please double check the fitment before making an order. Thank you!) Installation Instructions:
1. Disabling the vehicle’s fuel pump, disconnect the battery
2.Remove the air box system, throttle body, wiring harness connectors and the PCV valve and hose.
3.Remove Upper Intake Manifold cover and SCPI Fuel Meter Body
4.Remove the Fuel Meter Body bracket and replace it with the updated bracket.
5.Insert the MFI Fuel Meter Body into the Fuel Meter Body Bracket on the Lower Intake Manifold. Push down firmly on the fuel meter body locking it into the bracket.
6.Apply a coat of clean motor oil or non-silicone lubricant to the injector tip for easier installation.
7.Insert the number 3 injector into the correct hole in the Lower Intake Manifold first. Install the number 5 injector next and then number 1.
8.This sequence must be followed correctly to prevent interference of the Fuel Tubes. Injectors 2, 4, and 6 are then installed.
9.Temporarily reinstall the Fuel Inlet and Return Lines into the Fuel Meter Body.
10.Reconnect the battery and vehicle’s fuel pump.
11.Perform a Fuel Pressure System check to verify that the injectors are not leaking.
12.If everything is ok, reinstall the Upper Intake Manifold cover and Fuel lines.
