Top connectorsandSoftware Yamaha YDS 1.33andSuzuki SDS 8.70andEvinrude ETEC 5.9.0.0Diagnostic software
Professional diagnostic set forYAMAHAandSUZUKIandEvinrude ETEC!!!
+workshop manuals in .pdf
Designed and Testedby a Professional engineer!
You want to be able to check your Yamaha and Suzuki and Evinrude outboard/jetboard engine and you only have USB ports on your computer!
THIS SET INCLUDES:
- Yamaha YDSdiagnostic interface
- Suzuki SDS diagnostic interface
- Evinrude diagnostic interface with Bootstrap
Yamaha YDSdiagnostic interface
The Cable Replaces Discontinued Yamaha YDS Interface Cable
Part # 60V-WS850-00-00, 60V-WS850-00-02
This Set allows you to connect Yamaha YDS software 1.33 from your PC, Laptop, or Tabletto All EFI 4-Stroke and HPDI outboard Motors and Yamaha YDS-compatible (PWC)Waverunner's and Jet-Boat's, andAll Mercury Marine 75, 90, 115, and 225 EFI 4-Strokes manufacturedbyYamaha.
The set comes with one Professional-Grade USB to Engine Harness Plug (Interface Module Cable) and installation/instruction manual and Yamaha Diagnostic Software Version 1.33This set provides the same information a Yamaha Dealer would use to diagnose your Yamaha Outboard and PWC (Waverunner / Jet-Boat).
This set isalsocompatible with allMercury Marine75, 90, 115, and 225 EFI 4-Stroke outboards manufactured by Yamaha Marine.
You will be able to read all of your engine diagnostic codes and records, engine hours, activate low and high pressure fuel pumps, test individual injectors and ignition coils, set tilt-limit, de-activate most engine sensors for testing, view all sensor readings (TPS, IAC, battery voltage, charging voltage, rpm, oil pressure, MAP, etc..), stationary and static diagnostic tests, and many other functions. All data from your engine can be saved to your computer for future reference using Microsoft Excel.
OUTBOARD APPLICATIONS MODELS:
AllYamahaHPDI OUTBOARD MODELS
Z150 , LZ150 , VZ150 , Z175 , VZ175 , Z200 , LZ200 , VZ200 ,VZ200 ,Z225 , VZ225 , Z250 , LZ250 , VZ250 , Z300 , LZ300 , VZ300
AllYamahaEFI 4-STROKE OUTBOARD MODELSF30 , F40 , F50 , T50 , F60 , T60 , F70 , F75 , F90 , F115 , LF115 , F150 , LF150 , F200 , LF200 , F225 , LF225, F250 , LF250 , F300 , LF300 , F350 , LF350
(International Models)
AllYamahaHPDI models
Z150 , LZ150 , Z175 , LZ175, Z200 , LZ200 , Z225 , LZ225 , Z250 , LZ250 , LZ300 , Z300
AllYamahaEFI 4-Stroke Models
F30 , F40 , F50 , FT50 , F60 , FT60 , F70 , F75 , F80 , F90, F100 , F115 , FL115 , F150 , FL150 , F200 , FL200 , F225 , FL225 , F250 , FL250 , F300 , FL300 , F350 , FL350
AllYamahaYDS-compatible Personal Watercraft (Jet-Ski's/ Jet-Boat's)
JET-SKI MODELS
GP1300R , VX , VX CRUISER , VX DELUXE , VX SPORT , FX , FX CRUISER , FX HO FX CRUISER HO , FX SHO , FX CRUISER SHO , FZR , FZS , VX18R , VX18S
JET-BOAT MODELS
SR230 , SR230 HO , SX230 , SX230 HO , AR210 , AR230 , AR230 HO , SX210 , 212X , 212SS , 232 LIMITED , AR240 , AR240 HO , SX240 , AR190 , SX240 , SX240 HO, 242 LIMITEDMERCURY MARINE 225 (EFI 4-STROKE)
ALL MERCURY MARINE 75, 90, 115, and 225 EFI 4-STROKES MANUFACTURED BY YAMAHA MARINE
Important: The software will NOT work on Yamaha OX66 fuel injected engines, Yamaha carbureted engine.
Suzuki SDS marine diagnostic interface
ALL EFI DF 9.9 - DF 300Suzuki Outboard Motors
It works with:
DF 9.9
DF 25
DF70A/80A/90A- 2009 and later
DF90/115- 2001 and later
DF100- 2009 and later
DF140- 2002 and later
DF140- 2002 and later
DF100A/115A/140A- Serial number: 310001 and later
DF150/175- 2006 and later
DF150TG/ZG/175TG/ZG- Serial number: 410001 and later (new)
DF200A- Serial number: 510001 and later (new)
DF200AP- Serial number: 510001 and later (new)
DF200/225/250- 2004 and later
DF250S- 2008 and later
DF300- 2007 and later
DF250AP/300AP- Serial number: 310001 and later (new)
ThisSet enable you to connectAllEFI 4-Stroke toPC/Laptop
The set comes withall therequired harnesses, adapters, and cables.
You will be able to read all of your engine diagnostic codes and records, engine hours, activate low and high pressure fuel pumps, test individual injectors and ignition coils, set tilt-limit, de-activate most engine sensors for testing, view all sensor readings (TPS, IAC, battery voltage, charging voltage, rpm, oil pressure, MAP, etc..), stationary and static diagnostic tests, and many other functions. All data from your engine can be saved to your computer for future reference using Microsoft ExcelThe set comeswithall therequired adapters, and cables.
EvinrudeE-tec/FICHT diagnostic interface with cable BOOTSTRAP
Compatible with all models E-TEC, FICHT, DI 1999 up today:
E-TEC:25HP, 30HP, 40HP, 50HP, 55HP, 60HP, 65HP, 75HP, 90HP, 115HP, 130HP, 150HP, 175HP, 200HP, 225HP, 250HP, 300HP.
FICHT:75HP, 90HP, 115HP, 135HP, 150HP, 175HP, 200HP, 225HP, 250HP.
DI:100HP, 115HP, 135HP, 150HP, 175HP, 200HP, 225HP, 250HP.
Support function:
- Reading and resetting the fault code(s).
- Reading the EMM module identification.
- Reading sensors and actuators in real time.
- Reading of technical parameters in real-time.
- Tests operation of the electric fuel pump.
- Tests sensors and actuators in real time.
- Tests operation of the injectors and high voltage coils.
- Generating the graphics of engine operation.
- EMM software update (Allows the user the abilityto upload engine map software updates to the EMM).
- EMM recovery(allows tobring the system back to a communicating level).
- Reading the serial numbers of the injectors.
- Replace the injector and injector data file.
- Reading of temperature and voltage of the TPS.
- Printing or export of diagnostic data to PDF files.
- Other tests and analyzes.
Diagnostic Kit:Better than original Evinrude communications cable (p/n 437955).
Our diagnostic kit comes with the same chipset used in StarTech,is highly recommend for use in their official workshops
Works with the following Windows ® operating systems,one available USB port, and a DVD/CD-ROM drive for the software installation.:
- Microsoft® Windows® XP 32-bit and 64-bit operating systems.
- Microsoft® Windows® Vista 32-bit and 64-bit operating systems.
- Microsoft® Windows® 7 32-bit and 64-bit operating systems.
- Microsoft® Windows® 8, 8.1 32-bit and 64-bit operating systems.
- Microsoft® Windows® 10 32-bit and 64-bit operating systems.
Will not working on MAC computers.Shipping via priority express airmail with tracking number.
Package list:- 1 x USB Diagnostic adapter.
- 1 x Cablewith 3 pin diagnostic connector. (for Yamaha)
- 1 x DVD software YDS 1.33 (software, workshop manuals in .pdf, driver, manual)
- 1 x cable with 4 pin diagnostic connector (for Suzuki)
- 1 x cable with 8 pin diagnostic connector (for Suzuki)
- 1 x DVD software SDS 8.70 (software, workshop manual .pdf, driver)
- 1 x USB cablewith 3 pin diagnostic connector. (for Evinrude)
- 1 x cable Bootstrap for Evinrude
- 1 x DVD software ETEC 5.9.0.0 (software, workshop manual .pdf, driver)
