125CC 4 Stroke ATV Engine Motor w/Reverse Electric Start For ATVs GO Karts125CC 4 Stroke ATV Engine Motor
Description
If you are a driving enthusiast who loves freedom and pursues speed and passion, our 4-stroke ATV motor engine will be your ideal choice. Its excellent performance and stable power output make your driving more enjoyable and comfortable. Buying this 4-stroke ATV motor engine means choosing a high-quality, high-performance, and safe driving Type: Single Cylinder, 4 Stroke, Horizontal, Two-stage Transmission
Other Features: 3 Forward Gears and 1 Reverse
Material: Aluminium, Cast Steel
Engine Cooling Type: Air Cooling
Ignition System: CDI (Not Included)
Start Mode: ; Electric
Clutch Type: Manual Wet Multi-Disc
Transmission: 4-speed, Semi-Auto
Displacement: 125CC
Minimum No-load Stable Speed: 1400 (1 ± 10%) R / min
Compression Ratio: 8.7:1
Bore Stroke: 54*54mm/2.12*2.12inch
Max Power: 5.8Kw/h
Max Torque: 8.0N-m
Max Rotating Speed: 7500rpm
Horsepower: 7.64HP
Air Inlet and Exhaust Valve Clearance: 0.05 ~ 0.07 mm (Cold State)
Min Fuel Consumption: ≤367g/kW.h
Spark Plug: A7TC
Carburetor Type: PZ19 (Not Included)
Min Stable Idle Speed: 1500r/min±150r/min
Primary Reduction Ratio: 3.722
Transmission Ratio of Each Gear:First Gear: 3.272; Second Gear: 1.938; Third Gear: 1.350; Fourth Gear: 1.043
Lubricant Capacity: 900ml/0.23 Gallons
Lubricant Type: SL10W/40 (Not Included)
Crankshaft Diameter: 1.5cm/0.59inch
Crankshaft Length: 0.4cm/0.15inch
Gasoline Type: ≥ 92 #
Gross Weight: 19.45kg/42.87lbs
Net Weight: 18.15kg/40.01lbs
Product Size: Size: Features
Strong Power:This ATV motor engine boasts a robust 7.64HP horsepower, a displacement of 125cc, and a max rotating speed of 7500RPM, which provides you with strong power and ensures that your drive will be very smooth and powerful.
Durable and Sturdy: The engine is equipped with premium aluminum and cast steel, ensuring superior performance and a longer lifespan and adapting to complex environments and conditions.
Effective Cooling System: By adopting an air cooling system, the temperature of the engine can be quickly reduced, effectively preventing overheating and ensuring smooth and long-lasting driving.
Adjustable Speed:Its 4-speed manual transmission provides you with high-precision gear shifting control, so it allows you to easily adapt to various changes. It makes your driving experience more exciting under different road conditions.
Easy to Operate:The CDI ignition system (not included) leads to higher energy and ignition efficiency. So you can start the motor engine quickly and safely.
Easy to Install:Our ATV motor engine is pre-installed and you only need to spend a little time and effort to complete the remaining parts, enjoying a sense of achievement!
Closed Design:The closed design effectively prevents dust, water, oil, etc. from entering the machine, while minimizing the need for daily maintenance as much as possible.
Protective Packaging: This product comes in a custom foam that resistscommon compression and falls to prevent product damage in Oil Filter: It can help filter solid stains from lubricating oil, largely reducing wear and prolonging the engine service life.
Gearshift Shaft: It can control the vehicle\'s speed to suit different usage scenarios.
Shockproof Installation Hole: It is used to install shock absorbers to reduce vibration during driving, thereby improving its driving comfort.
Forged Crankshaft:It adopts a high-quality metal design to ensure high safety and stability during operation.
Clear Wires:The different wires have different colors, thus easily distinguishing and connecting them without product can be widely used in motorcycles, ATVs, go-karts, tricycles, etc, as long as the crankshaft matches.
Package Included
1*ATV Motor Engine
1*Gearshift Lever
1*ChainCover
1*Intake Manifold
2*Intake Gaskets
All Accessories for installation is highly recommended.
