Built-in GPS + 4G LTE + Wi-Fi 6 – multiple ways to navigate and stay Check Installation Size Before OrderingThe UX7SK Plus is a universal Double DIN car stereo, not a vehicle-specific head unit.
Do not purchase based on vehicle make, model or year alone.
Main Installation Dimensions
- Required dashboard opening: 178 × 100mm
- Double DIN chassis: 178 × 100mm
- Chassis depth: approx. 80mm
- Screen size: approx. 247 × 162mm
Your vehicle must have sufficient dashboard space for both the chassis and the larger 10.1" display.
Not for a Standard Single DIN Opening
If your vehicle currently has a standard 178 × 50mm Single DIN radio opening, this unit is not a direct-fit replacement.
Please check a compatible Single DIN solution instead, unless your vehicle can be professionally converted to accommodate a Double DIN Installation Parts May Be Required
Even when your dashboard can accommodate a Double DIN stereo, some vehicles require additional installation parts.
Depending on your vehicle, you may need:
- Vehicle-specific fascia / dash kit
- ISO wiring harness
- Antenna adapter
- Steering wheel control adapter
- CANBUS interface
These vehicle-specific parts are not included unless specifically stated in your selected package.
Check the Factory Wiring
The supplied connection is designed around a compatible ISO-standard interface.
If your original radio does not use the required ISO connection, a compatible vehicle-specific ISO wiring harness will be required.
Before ordering, check both:
Dashboard size + original wiring connection
Adjustable 10.1" QLED Touchscreen
The large 10.1-inch QLED display gives navigation, media and compatible camera images considerably more viewing space than a conventional fixed Double DIN screen.
- 1280×720 HD resolution
- QLED display
- Anti-glare design
- Capacitive touchscreen
- Adjustable viewing angle
- Adjustable screen position
The display can be positioned to better suit the driver's viewing angle and dashboard layout.
Because the screen is substantially larger than the Double DIN chassis, check the surrounding clearance before purchase, including:
- Air vents
- Climate controls
- Hazard switch
- Dashboard buttons
- Gear selector area
The screen measures approximately 247 × 162mm, so measuring the available dashboard space beforehand can help avoid installation problems.
Physical Knob for Everyday Control
Unlike touchscreen-only designs, the UX7SK Plus includes a practical physical control knob.
Use it to:
- Adjust volume
- Short press for mute on/off
- Long press for power on/off
This provides quick access to common controls without relying entirely on the touchscreen.
Android 14 + Qualcomm Performance
Powered by the Qualcomm QCM6225-AD 6nm platform, the UX7SK Plus provides the performance needed for navigation, music and compatible Android apps.
- 8-Core CPU: 4×A73 up to 2.8GHz + 4×A53 up to 1.9GHz
- 6GB RAM
- 64GB internal storage
- 1-second fast boot supported
- OTA firmware updates
- Split-screen multitasking
Run compatible functions such as navigation and music side by side for easier access while driving.
Wireless Apple CarPlay & Android Auto
Connect your compatible smartphone and bring commonly used phone functions onto the larger display.
Access compatible:
- Navigation
- Music
- Calls
- Messages
- Siri
- Google Assistant
Both wired and wireless Apple CarPlay and Android Auto are supported, giving you the flexibility to use a cable or connect wirelessly.
Note: Full phone screen mirroring is not supported.
48-Band DSP + DTS Audio Control
Adjust the sound to suit your speakers, vehicle cabin and listening preferences.
Audio features include:
- Built-in DSP
- 48-band EQ
- DTS audio processing
- Multiple EQ presets
- Subwoofer control
- 30W RMS manufacturer-rated power
- Up to 4×50W amplifier output
- 5-channel preamp output
For upgraded audio systems, the UX7SK Plus provides 4 RCA outputs plus optical and coaxial digital outputs, giving you more connection options for compatible aftermarket amplifiers and subwoofers.
Built-In GPS Navigation
The built-in GPS receiver and external GPS antenna allow the stereo to work with compatible navigation apps.
Use compatible offline maps when mobile data is unavailable, or connect to the internet for supported services such as Google Maps and Waze.
Offline navigation can be particularly useful on longer journeys or in areas with limited mobile coverage.
4G LTE + Wi-Fi 6 Connectivity
Insert a compatible SIM card to give the stereo its own mobile data connection for supported navigation, streaming and Android apps.
Connectivity includes:
- Built-in 4G LTE module
- 2.4GHz / 5GHz Wi-Fi
- Wi-Fi 6 ready
- Bluetooth 5.1
- Split-screen multitasking
A SIM card is not required for Apple CarPlay, Android Auto, Bluetooth, AM/FM radio or GPS reception.
4G compatibility depends on the regional version, carrier and supported LTE bands.
Steering Wheel Control Support
The UX7SK Plus supports compatible analogue steering wheel controls.
If your vehicle uses digital or CANBUS-based steering wheel controls, a compatible vehicle-specific interface may be required.
Because steering wheel control systems vary considerably between vehicle manufacturers and model years, please check your original wiring before purchasing.
Camera, Radio & Media Support
Add compatible accessories and media sources to expand the system.
Supported features include:
- Reversing camera input
- Automatic reverse display
- Parking guidelines
- AM/FM radio with RDS
- 3 USB inputs
- USB media playback
- Up to 1080P video decoding
Common audio formats including MP3, WMA, WAV, AAC, FLAC and APE are supported.
Optional Eonon Accessories
A100 Dash Camera
Add compatible front driving recording.
A0125 / A0127 Camera
Add compatible parking or reversing-camera functionality.
V0056 Bluetooth OBD2 Scanner
View supported vehicle diagnostic information through compatible Android apps.
A0593 / A503 / DX2 / DX1 DAB+ Digital Radio
Add DAB+ reception in supported UK, European and Australian regions.
A304 DSP Digital Amplifier
Add further amplification for compatible upgraded audio systems.
Optional accessories are sold separately unless specifically included with your selected package.
Frequently Asked Questions
Will the UX7SK Plus fit my car?
It can be installed in many vehicles that can accommodate a 178 × 100mm Double DIN chassis, but fitment also depends on dashboard shape, wiring and clearance for the 247 × 162mm display.
My factory radio is Double DIN but the opening is not exactly 178 × 100mm. Can I still install it?
A vehicle-specific fascia or installation kit may allow installation in some vehicles. The required kit is not included and must be selected according to your vehicle.
My car has a Single DIN radio. Will it fit?
It is not a direct replacement for a standard 178 × 50mm Single DIN opening. A suitable dashboard conversion would be required, otherwise a Single DIN stereo is the more appropriate option.
Do I need an ISO wiring harness?
If your vehicle does not already have the compatible ISO-standard connection required by the stereo, a vehicle-specific ISO adapter harness will be needed.
Will the large screen block my air vents or controls?
This depends on your dashboard. The screen measures approximately 247 × 162mm, so please measure the available area and check the listing installation images before ordering.
Can the screen position be adjusted?
Yes. The display position and viewing angle can be adjusted to better suit compatible dashboard layouts.
Does it have a physical volume knob?
Yes. The physical knob provides volume adjustment as well as mute and power functions.
Does it support Wireless CarPlay and Android Auto?
Yes. Both wired and wireless Apple CarPlay and Android Auto are supported.
Can GPS work without internet?
Yes. The built-in GPS supports compatible offline navigation maps. Internet access is required for online traffic and other connected services.
Do I need a SIM card?
Only if you want to use the stereo's built-in 4G LTE mobile data connection. CarPlay, Android Auto, Bluetooth, radio and GPS reception do not require a SIM card.
Will my steering wheel controls work?
Compatible analogue steering wheel controls are supported. Digital or CANBUS-based controls may require a vehicle-specific adapter.
Can I connect an aftermarket amplifier or subwoofer?
Yes. RCA, subwoofer, optical and coaxial outputs are available for compatible aftermarket audio equipment.
A Flexible Double DIN Upgrade for Modern Driving
The Eonon UX7SK Plus Android Double DIN car stereo combines Android 14, Qualcomm 6nm performance, Wireless Apple CarPlay and Android Auto, a large adjustable 10.1" QLED display, built-in GPS, 4G LTE and advanced DSP audio in one versatile system.
Its 178 × 100mm Double DIN chassis, adjustable display and physical control knob make it particularly suitable for drivers who want a larger, more flexible infotainment setup than a conventional fixed-screen Double DIN radio.
Before purchasing, measure your dashboard opening and screen clearance, and check whether your vehicle requires a fascia kit, ISO wiring harness or steering wheel control adapter.
⭐Technical Specifications
- Operation system: Android 14
- OTA Firmware Update: Yes
- Processor: Qualcomm QCM6225-AD
- CPU Architecture: 8-core(4×[email protected] + 4×[email protected])
- RAM: 6GB
- Storage: 64GB
- Display: 10.1" QLED Touchscreen
- Resolution: 1280*720
- Operating voltage: DC12V
- Physical button/knob: Yes
- CarPlay: Wired & Wireless
- Android Auto: Wired & Wireless
- Split-screen multitasking: Yes
- Adjustable viewing angle: Yes
- Screen mirroring: No
- 1s fast boot: Yes
- Steering wheel controls: Yes
- Key button color: Variable
- Wi-Fi: Support 2.4G/5G & Wi-Fi 6 ready
- 4G feature: Built-in 4G module
- Custom boot logo & changeable wallpapers: Yes
- Built-in UI themes: 1
- Built-in DSP: Yes
- Built-in power amplifier: 4-channel audio output and 2 subwoofer audio output
- EQ bands: 48
- EQ modes: User Standard Rock POP Classical Jazz Gentle CINEMA Hall
- HPF/LPF adjustment: No
- Video input: 1
- Video output: No
- Audio input: 2
- Audio output: 4 RCA + 1 Optical + 1 Coaxial
- AUX input: No
- USB input: 3
- RMS power (manufacturer): 30W
- Max amplifier output: 4*50W
- Preamp outputs: 5-channel
- Sub preamp outputs: Yes
- Video Formats: Supports MPG, DAT, TS, AVI, MP4, MOV, 3GP, ASF, VOB, MKV, FLV, RM, RMVB, and more; supports 1080P video decoding
- Audio Formats: Supports MP3, WMA, WAV, OGG, AAC, FLAC, APE, and more; online audio playback supported
- Image Formats: Supports JPEG, BMP, PNG, and more
