Product Description Nilight 360W 36V/48V to 12V 30A DC-DC Converter
Our DC voltage reducer converters are high reliability power transformers. They feature wide input voltage, low power consumption, high efficiency, high reliability. We provide different power voltage converters for all kinds of application devices.
Specification Model Nilight 360W 36V/48V to 12V 30A DC-DC Converter Efficiency 96% Input voltage DC 36/48V Output voltage DC 12V Output current 30A No load current 0.01A Voltage accuracy ±1.5% Load regulation rate ±0.2% Linear adjustment rate ±0.2% Waterproof rating IP 67 Operating Temperature -40~85°C Package Included 360W 36V/48V to12V 30A DC-DC Converter with fuse*1, Quick Connect Ternimal*2, 25A Fuse*1 Wiring Diagram
If the converter doesn't work, check the following steps: 1.Check whether the power supply has a voltage;2.Whether the terminals are in poor contact and whether the wire ends are connected securely;3.Check whether the wires are installed as shown in the picture.
Product Details Quick Connect Terminals
Come with 2 pcs quick connect terminals, make it easy to use.
When you make electrical connection, only need a little force to push the lever up.
Strict Glue Pouring Process
Strict glue pouring process aluminum shell and silicone sealed design.
Waterproof, moisture-proof, seismic.
Adapt to a variety of harsh environment.
Better Heat Dissipation
Die-casted Aluminium shell
Excellent corrosion resistance
Improve better heat dissipation effect
Sturdiness to extend service life.
Advance Chip
Assembled with smart chip features of Over-current /Over-load /Low-load /Short-circuit /Over-heat intelligent protection.
Synchronous Rectification Technology
Over-current Protection
Over-load Protection
Low-load Protection
Short-circuit Protection
Over-heat intelligent Protection
Anti-Reverse Fuse
With anti-reverse fuse holder. When the wire is reversed or overloaded, the fuse will be blown. At this time, replacing the fuse and the fuse and rewiring without overload can prevent the reverse connection caused by the damage of electrical appliances effectively.
-
-
