Product Description:Part: Steering Rack and PinionRack Type:Hydraulic SCITOO Complete Power Steering Rack & Pinion Assembly For 1985-1993 Ford Mustang
Part: Steering Rack and Pinion
Rack Type:Hydraulic
Casting Material : Steel/Aluminum
Package Contents : Rack and Pinion, Installation Kit, Instruction Sheet
Product Condition : Remanufactured
Number of Mounting Holes : 2
Hose Port Type : Teflon
Tie Rod Ends Included : Inner
Total Turns Lock To Lock : 3.31
Pressure Port Thread Size : 9/16 x 18
Return Port Thread Size : 5/8"- 18
Rack Length (mm) : 1231.90
Thread Length (In) : 3.63
Thread Length (mm) : 92.20
Distance Between Mounting Holes (in) : 15.50
Distance Between Mounting Holes (mm) : 393.70
Steering Rack Color : Black
Input Shaft Diameter (in) : 0.73
Input Shaft Diameter (mm) : 18.62
Input Shaft Length (in) : 2.80
Input Shaft Length (mm) : 71.12
Rack Length (in) : 48.50
Other Part Number:
- 22-216 Rack 290 + ES3184 Rack 290 ; ES3184, 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004
Product Description:
Steering gear,also called steering gear, is the most important part of automobile steering system.
Power steering (PAS) or steering assist system helps drivers steer by augmenting steering effort of the steering wheel.
Power steering rack and pinion is the most important part for vehicle swerving and security assurance.
It converts the rotational motion of the steering wheel into the linear motion needed to turn the wheels and provides a gear reduction,
thus making it easier to turn the wheels.
Compatible with the following vehicles:
FORD MUSTANG 1999-2004 V-6 Engine
note:
1.In order to avoid the fault caused by the dirt entering the steering oil circuit, the plug on each oil port of steering pump of steering gear shall be opened before connecting the oil pipe, and the oil pipe and plug shall be carefully cleaned and deburred.
2. Turn the steering wheel to the straight ahead position.
3. Clean the mounting bracket of the steering gear and relevant mating surfaces of the steering gear.
4. For the adjustable steering column, use a suitable rope to pass through the space of the cross fork of the steering shaft, hang the steering shaft, and connect the steering shaft and the input shaft of the steering gear.
5. Turn the steering gear to the middle position to align the relevant marks at the input end and output end of the steering gear.
6. Install the steering gear on the mounting base and tighten the fixing bolts.
7. Universal joint or coupling between mounting column and steering gear.
8. For the adjustable steering column, the upper end seal of the steering gear shall not be damaged when the universal joint is installed.
9. Keep the steering wheel in straight ahead position.
10. Put the pitman arm on the steering gear to align the two marks. 10. Tighten the locknut according to the specified torque and rivet (anti loose pit)
SCITOO Complete Power Steering Rack & Pinion Assembly For 1985-1993 Ford Mustang
