GT TURBO PARTSBUILT FOR BOOSTPERFORMANCE TURBOCHARGERGTX2563R-47Ball Bearing Performance TurboForged compressor wheel • T25 turbine inlet • 76mm V-Band outlet • Wastegated200–350HPPOWER RANGE1.6–2.5LDISPLACEMENT0.64 A/RTURBINE HOUSINGBALLBEARINGForged CW47mm inducer / 63mm exducer forged compressor wheel.Ball BearingBall bearing center housing configuration.T25 InletT25 turbine inlet with 76mm V-Band outlet.WastegatedWastegated turbine housing configuration.Key FeaturesGTX2563R-47 Configuration
GT25-size performance turbocharger configuration for custom turbo applications.Forged Compressor Wheel
47mm inducer and 63mm exducer forged compressor wheel specification.0.60 Compressor A/R
76mm compressor inlet and 51mm compressor outlet.0.64 Turbine A/R
T25 inlet, 76mm V-Band outlet and wastegated turbine housing.Reference RANGE200–350 HPDISPLACEMENT1.6–2.5LTechnical SpecificationsCompressorCompressor Wheel Inducer47 mmCompressor Wheel Exducer63 mmCompressor WheelForgedCompressor Inlet76 mmCompressor Outlet51 mmCompressor A/R0.60TurbineTurbine Wheel Inducer53 mmTurbine Wheel Exducer43 mmTurbine InletT25Turbine Outlet76mm V-BandTurbine A/R0.64Turbine TypeWastegatedCenter HousingBearing TypeBall BearingOil Inlet7/16-24 × AN4Oil OutletM8 × 1.25-38Water FeedM14 × 1.5Application RangePower Range200–350 HPEngine Displacement1.6–2.5LProduct InformationThe GTX2563R-47 combines a 47/63mm forged compressor wheel with a 53/43mm turbine wheel, ball bearing center housing and a 0.64 A/R wastegated turbine housing.
The turbo features a 76mm compressor inlet, 51mm compressor outlet, T25 turbine inlet and 76mm V-Band turbine outlet, making it suitable for custom performance turbo applications using compatible flange, connection and installation dimensions. Universal Fitment VerificationThis is a universal performance turbocharger and is not listed as a direct bolt-on replacement for a specific vehicle.
Please verify turbine inlet, turbine outlet, compressor inlet, compressor outlet, oil and water connections, wastegate configuration, available installation space and overall turbo dimensions before purchase.Recommended Applications• Custom turbocharged performance builds
• 1.6L–2.5L engine applications
• Approximately 200–350 HP target range
• Applications using a T25 turbine inlet
• Applications using a 76mm V-Band turbine outlet
• Custom street, track and performance projectsFitment & Installation NotesProfessional installation is recommended.
Correct oil supply, oil drain, water connections, intake routing, exhaust manifold compatibility, downpipe fitment and wastegate setup must be confirmed for each application.
Turbocharger selection should be matched to engine displacement, target power, fuel system, ECU calibration and supporting modifications.FAQQ: Is this GTX2563R-47 ball bearing?
A: Yes. This turbo uses a ball bearing center housing.
Q: What compressor wheel does it use?
A: It uses a forged compressor wheel with a 47mm inducer and 63mm exducer.
Q: What is the turbine housing A/R?
A: The turbine housing is 0.64 A/R.
Q: What flange configuration does it use?
A: It uses a T25 turbine inlet and 76mm V-Band turbine outlet.
Q: What engine displacement is recommended?
A: The reference displacement range is 1.6L–2.5L.
Q: What is the reference power range?
A: The reference power range is approximately 200–350 HP.
Q: Is this a direct bolt-on turbo?
A: This is a universal performance turbocharger. Fitment must be verified for each individual installation.24H FAST DISPATCHOrders are prepared for dispatch within 24 hours.6-MONTH WARRANTYCovered by our 6-month product warranty.30-DAY RETURNS30-day return policy applies according to listing terms.NEED HELP CHOOSING A TURBO?Send us your engine displacement, target horsepower and current turbo setup. We will help you check the most suitable option.GT TURBO PARTS • PERFORMANCE TURBOCHARGER COMPONENTS
