WE "ONLY" NEED YOUR VIN NUMBER! :)
CONTACT US AT THE NUMBER BELOW WITH ANY QUESTION.
Mercedes Benz 7G Tronic722.9 TCM Conductor Plate PROGRAMMING Service
+
722.9 Conductor Plate VGS 1/2/3
THIS IS FOR MERCEDES BENZ 7G TRONIC 722.9 VGS1/2/3
CONDUCTOR PLATE "AND" SERVICE TO PROGRAM UNIT TO YOUR VIN
FAST SHIPPING DIRECTLY TO YOU
SAVING YOU TIME AND MONEY
WHAT WE DO....
- VIRGINIZE A TESTED UNIT
- PROGRAM YOUR VIN AND VEHICLE MODEL YEAR INFORMATION
- PROGRAM YOUR EHS NUMBER THAT IS STAMPED ON THE SIDE OF YOUR VALVE BODY
- FLASH THE CONTROL UNIT WITH YOUR VEHICLES REQUIRED SOFTWARE
- ECU SCN CODE YOUR CONTROL UNIT
- WE RELEASE THE TRANSPORT PROTECTION AND ACTIVATE YOUR UNIT
WHAT INFORMATION DO WE NEED
- VIN NUMBER (INCLUDE VIN IN CHECKOUT USING "MESSAGE TO SELLER" OR SIMPLY MESSAGE IT TO US.
- THATS IT!!!
CONTACT US WITH ANY QUESTIONS
512 ! 608 ! 0521
VGS VERSIONS IN STOCK WILL VARY
CONTACT US TODAY WITH YOUR VIN!
FAQs
Q. Is it plug and play?
A. Yes BUT..., No further programming or coding is required. We've done it all. Just do the adaptation initialization steps and range sensor learning with most bi-directional scan tool and that’s it. You're back on the road.
*SIMPLE INSTRUCTIONS AND SUPPORT CONTACT NUMBER INCLUDED WITH YOUR UNIT
Q.What is done to the plate before shipping?
A. We inspect and test each unit before it enters our stock
Q. Is the handling time actually 4 days?
A. Some buyers take longer than others getting the need info which was effect our rating. Most orders ship n 1-2 days
Q. DO I need EHS?What if I cannot get the EHS number
A. No, we normally can find it in 99% of cases using your VIN information. So no need to remove first.
Q. Is there any warranty?
A. Yes, you have a 30 day warranty and covered by 30 day Guarantee
Q. Do I need to send my original plate? Can I send it?
A. No need to send us your plate. We can do everything we need with the information you provide. If you would like to transfer your adaptation data from your original plate we can rent you our scan tool to copy your information once your new unit arrives.
Q. Is there any kind of support?
A. Check out our response. Top notch support before and after the sale. Customer get our direct support number for and questions or issues that may arise.
Transmission Control Unit TCM / TCU Siemens VDO / Continental
Part number:
·A 0335456632
·A 0335456732
·A 0335457232
·A 0335457332
·A 0034460310
Error:
·Y3/8Y1 WORKING PRESSURE CONTROL SOLENOID
·Y3/8Y2 K1 CLUTCH SOLENOID
·Y3/8Y3 K2 CLUTCH SOLENOID
·Y3/8Y4 K3 CLUTCH SOLENOID
·Y3/8Y5 B1 BRAKE CLUTCH SOLENOID
·Y3/8Y6 B2 BRAKE CLUTCH SOLENOID
·Y3/8Y7 B3 BRAKE CLUTCH SOLENOID
·Y3/8Y8 TORQUE CONVERTER LOCKUP SOLENOID
·Y3/8S1 SELECTION RANGE SENSOR
·Y3/8N1 TURBINE SPEED SENSOR
·Y3/8N2 INTERNAL SPEED SENSOR
·Y3/8N3 OUTPUT SPEED SENSOR
·Y3/8N4 FULLY INTEGRATED TRANSMISSION CONTROL
Errors:
·0641 Component Y3/8n4 (Fully integrated transmission control (VGS) control
unit) defective
·0642 The voltage supply of the speed sensors is faulty.(Undervoltage)
·0705 Component Y3 / 8S1 (selection area sensor (VGS)) is defective
·Check 0706 Component Y3/8S1 (Range Sensor (VGS) Selection)
·0717 The signal from component Y3 / 8n1 (turbine speed sensor (VGS)) not available
·0718 Component Y3 / 8n1 (Turbine Speed Sensor (VGS)) Defective
·0722 The signal from component Y3 / 8N3 (Output speed sensor (VGS)) not available
·0723 Component Y3/8N3 (Output Speed Sensor (VGS)) is defective
·0748 The internal electrical test of component Y3/8y2 (K1 clutch control solenoid valve (VGS)) failed
·0778 The internal electrical test of component Y3/8y5 (B1 Brake Control Solenoid Valve (VGS)) failed
·0798 The internal electrical test of component Y3/8y7 (B3 Brake Control Solenoid Valve (VGS)) failed
·2216 check component Y3/8S1 (selection range sensor (VGS)) The adjustment sequence occurred outside of the valid range
·2716 The internal electrical test of component Y3/8y4 (K3 clutch control solenoid valve (VGS)) failed
·2725 The internal electrical test of component Y3/8y6 (B2 brake control solenoid valve (VGS)) failed
·2734 The internal electrical test of component Y3/8y3 (K2 clutch control solenoid valve (VGS)) failed
·2759 The internal electrical test of component Y3/8y8 (torque converter lockup clutch control solenoid valve (VGS)) failed
·2766 Too high speeds have occurred on components Y3 / 8n2 (internal speed sensor (VGS))
·2767 The signal from component Y3 / 8n2 (Internal speed sensor (VGS)) not available
·2768 Component Y3 / 8n2 (internal speed sensor (VGS)) is defective
·2810 The internal electrical test of component Y3 / 8y1 (working pressure control solenoid valve (VGS)) failed
Other diagnostic error:
·0604 , 0605 , 0607 ,060A , 060C , 0613 , 061B , 062F , 0633 , 0641 ,
·0651 , 06A3 , 0701 , 0711 , C300 , 1610 , 1629 , 1631 , 1632 , 1633 , 1634 ,
·1636, 1638 , 1639 , 1693 , 1710 , 1711 , 1712.
