Description
All modifications must be installed by licensed mechanics and in compliance with your local modification Honda/Acura K24 Series K24A1 K24A2 K24A3 K24A4 K24A6 K24A8 K24Z 2.4L
For K24A1：For Honda CR-V 2002–2006
For K24A2：For Acura TSX 2004–2008
For K24A3：For Honda Accord 2003–2007, Honda Odyssey 2004–2008
For K24A4：For Honda Accord 2003–2014, Honda Element 2003–2006, For Honda Odyssey 2003–2008
For K24A6：For Honda Accord 2004–2007, Honda CR-V 2005–2006, For Honda Element 2006–2008
For K24A8：For Honda Accord 2006–2007, Honda Element 2007–2011, For Honda Odyssey 2008–2014
For K24Z Series (K24Z1/K24Z2/K24Z3/K24Z6/K24Z7)：
ForHonda CR-V 2007–2012, Honda Accord 2008–2013, For Acura TSX 2009–2014, Honda Civic Si 2012–2015, For Honda Element 2009–2011
Pin Type: Floating Pin />
Connecting Rod Length Center to Center: 152.00mm/5.984in
Approximate Connecting Rod Weight: 528g
Big End Bore Diameter: 51.00mm/2.008in
Pin End Bore Diameter: 22.00mm/0.866in
Big End Width: 19.80mm/0.780in
Small end width: Style: H-beam Street/Strip
Material: 4340 Chromoly Steel
Finish: Shot-peened
Wrist Pin Style: Floating
Clearanced for Stroker: Yes
Cap Retention Style: Through-bolt
Connecting Rod Bolt Brand: ARP
Connecting Rod Bolt Diameter: 3/8\"
Connecting Rod Bolt Material: Alloy Steel
Fastener Yield Strength (psi): 220,000 psi (ARP 2000)
Upgrade Fasteners: ARP L19 (260,000 psi) optional
CNC Machined: High Precision
Rod Cap Alignment: Precision dowels
Bore Tolerance: ±0.005 mm
Balancing: ±1 gram per rod
Weight Matched Set: Yes
Remanufactured: No
Testing: Magnafluxed, X-rayed, Ultrasonically tested
Heat Treated: Yes
Performance Ratings
Advertised Horsepower Rating: 200HP/piece
Advertised RPM Rating: Sold as a set of 4
Package Size: 28CM*20CM*10CM
